28
52
52. Orient the Backrest (25) and a Cushion Frame
(9) as shown.
A
ttach the Backrest (25) to the Cushion Frame
(9) with four M6 x 16mm Screws (62).
62
25
9
62
53. Insert the Cushion Frame (9) into the Upright
(5).
Tighten an Adjustment Knob (29) into the
Upright (5) and one of the holes in the Cushion
Frame (9). Make sure that the Adjustment
Knob is engaged in a hole.
53
9
5
29
