11
11. Orient the Seat (8) as shown, and attach it to the
Frame (1) with four M6 x 65mm Screws (17) and
four M6 Washers (22); start all the Screws, and
then tighten them. To avoid damaging the
Seat, tighten the Screws only until the Seat
does not move or feel loose.
10. Orient the Backrest (7) as shown, and attach it
to the Backrest Frame (5) with four M6 x 16mm
Screws (24); start all the Screws, and then
tighten them. To avoid damaging the
Backrest, tighten the Screws only until the
Backrest does not move or feel loose.
1
5
8
10
11
22
12. Make sure that all parts of the weight bench are properly tightened. Extra parts may be included. Place a
mat under the weight bench to protect the floor.
7
17
24
24
