Please Note: The assembly is divided into five stages: 1) frame assembly, 2) press and butterfly
arm assembly, 3) cable and pulley assembly, 4) seat and backrest assembly, and 5) VKR assem-
bly. The hardware for each stage is packaged separately. Wait until you begin each assembly
stage to open that parts bag.
REMOVE THIS PART IDENTIFICATION
CHART FROM THE MANUAL
This chart is provided to help you identify the small parts used in assembly. Important: Some parts
may have been pre-assembled for shipping purposes. If you cannot find a part in the parts bags,
check to see if it has been pre-assembled. The number in parenthesis below each part refers to the
key number of the part. The second number refers to the quantity needed for assembly.
R1295A
