10
12. Insert a Base Stabilizer (9) into the Base (7).
Attach the Base Stabilizer with five M10 x
18mm Screws (34) and five M10 Washers (35).
Attach the other Base Stabilizer (9) to the
Base (7) in the same way.
11
12
11. Insert the Curl Post (6) into the Front Leg (4).
Insert the Curl Post Knob (24) into the Front
L
eg (4) and into one of the adjustment holes in
the Curl Post (6), and tighten the Curl Post
K
nob. Make sure that the Curl Post Knob is
inserted through one of the adjustment
holes.
6
4
2
4
9
9
34
34
34
35
35
7
