12
16. Make sure that all parts are properly tightened before you use the weight bench.
29
11
13
17
29
1
1
15. Attach the tether on a Large Pin (13) to the
underside of a Spotter (29) with an ST4.2 x
10mm Screw (17).
Hold the Spotter (29) on the indicated side of
a
n Upright (11), and align the Spotter with one
of the adjustment holes in the Upright. Insert
the Large Pin (13) through the Spotter and the
Upright.
Attach the other Spotter (29) to the other
Upright (11) in the same way. Attach both
Spotters at the same height.
15
