M10 Nylon
Locknut (94)
M8 Washer (95)
M8 Nylon
Locknut (97)
M6 Washer (98)
M6 x 16mm
Screw (105)
M8 x 22mm
Bolt (108)
M4 Washer (87)
M
M4 x 12mm
Self-tapping
Screw (123)
M4 x 16mm
Self-tapping
Screw (102)
M4 x 60mm Self-tapping Screw (122)
M10 x 45mm Bolt (104)
M6 x 63mm Screw (106)
M6 x 39mm Screw (107)
M10 x 40mm
Button Bolt (109)
M10 x 20mm
Bolt (110)
M10 x 50mm Bolt (111)
M
M6 x 57mm Screw (113)
M10 x 60mm Bolt (117)
M
M10 x 60mm Button Bolt (126)
M10 Washer (96)
PART IDENTIFICATION CHART A
Refer to the drawings below to identify small parts used in assembly. The number in parentheses by each draw-
ing is the key number of the part, from the PART LIST on page 31 of this manual.
Note: Some small parts may
have been pre-attached. If a part is not in the parts bag, check to see if it has been pre-attached.
5
