This chart is provided to help you identify the small parts used in assembly. The number in parenthesis below
each part refers to the key number of the part from the PART LIST on page 13. Important: Some parts may
have been pre-assembled for shipping purposes. If you cannot find a part in the parts bags, check to
see if it has been pre-assembled.
M10 x 60mm Bolt (18)
M8 Nylon Locknut (13)
M8 Washer (29)
M10 Nylon Locknut (19)
M8 x 50mm Bolt (17)
M6 Washer (25)
M8 x 55mm Bolt (27)
M6 x 16mm Screw (15)
M6 x 38mm Screw (16)
M8 x 65mm Bolt (14)
M8 x 40mm Carriage Bolt (26)
7mm Spacer (24)
PART IDENTIFICATION CHART
