PART IDENTIFICATION CHART
Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. Note: If a part is not in
the hardware kit, check to see whether it has been preassembled. Extra hardware may be included. If a
part is missing, call 1-877-992-5999.
M10 x 95mm Bolt (19)–32
M10 x 20mm Screw (22)–4
M10 Split Washer
(23)–8
M10 Washer
(20)–20
M10 Locknut
(21)–28
