Overview「5」
1.3 Typical Example of Wiring Diagram
CHARGE
L1
L2
L3
L1C
L2C
B1
B2
B3
1
2
U
V
W
C
N
1
C
N
2
C
N
3
C
N
4
Noise Filter
Circuit Breaker
PC
WISE servo driver
Magnetic Contactor
Regenerative Resistor
Protect the power line by shutting
the circuit OFF when over-current
is detected.
Used to eliminate external noise
from the power line and noise
disturbance form the driver.
Turn the servo ON and OFF.
Install a surge suppressor on
the magnetic contactor.
Note:
Used to start/stop the
rotation of motor is
PROHIBITED.
Contactor B1、B2、B3:
§ Keep short-circuit wiring
between B2-B3 contactors.
§ When a regenerative resistor is
equipped, break the short-circuit
wiring between B2-B3
contactors, and externally
connect regenerative resistor to
B1-B2 contactors, together set
Pr016 to 1.
Motor Main
Circuit Cable
Encoder Cable
Weihong CNC system
NK300BX
NcStudio V9
仿真
俯视图
X：
Y：
Z：
-1.978
6.248
5.000
X
Y
Z
内存：2M/8M 提示：方向键可调整视图位置（详细请按“G”键）
-10 0 10 20 30 40 50
-
2
0
-
1
0
0
1
0
2
0
3
0
4
0
自行车.dxf
08:58:06
空闲：正常结束
仿真
加 工
模拟仿真
F1
图形调整
F2
加工统计
F3 F4
加工范围
F5 F6
工件计数范围
F7 F8
已加工时间：
完成百分比：
预计剩余时间：
当前程序行：
当前刀具号：
完成工件数：
00:00:00
0%
00:04:08
0
1
0
F ：
S ：
0%
50%
0 mm/min
0 RPM
02300 G0 X-11.3589 Y6.6469 Z5.0000
02301 G1 Z0.0000
02302 G1 X-11.3589 Y6.6469
02303 G1 Z0.0000
02304 G1 X-12.2148 Y6.9251
02305 G1 Z0.0000
02306 G1 X-12.2148 Y6.9251
02307 G1 Z0.0000
02308 G1 X-11.9367 Y7.7810
02309 G1 Z0.0000
02310 G1 X-11.9367 Y7.7810
F1 F2 F3 F4 F5 F6 F8F7
Fig. 1-7 Typical example of wiring diagram
When externally wiring to a regenerative resistor, over-temperature protection
MUST be provided.
Install over-temperature protection fuse and thermostat in the regenerative
resistor. And once fuse action occurs, it cannot restore to previous state.
Please install the regenerative resistor on non-combustion substances.
