「6」WISE (维智) Driver
2 WISE (维智) Driver
2.1 Ordering Information of the WISE (维智)
Servo Driver
Contents of nameplate of WISE (维智) series servo driver, as shown Fig. 2-1, consists of series name +
permissible current specification + voltage specification + contactor specification + encoder feedback
type + control mode.
Symbol Type
WSDV WISE series
2
Symbol
Rated output
power
2R8 0.4kW
W S D V
2R8 2 0P S B
Current specification
5R0 0.75kW
6R8 1.0kW
110 1.5kW
Symbol Specification
2 200V
4 400V
Voltage
specification
Symbol Specification
0P Pulse train command
0C High -speed communication command
Contactor Specification
AP Analog voltage·pulse train command
Symbol Specification
P Parallel 2500-wire incremental encoder
S Serial communication encoder
Encoder feedback type
Symbol Specification
B Position/Velocity/Torque
P Exclusive for position control
Control mode
Fig. 2-1 WISE ordering options
2.2 Technical Specification
Table 2 Table of technical specifications
Basic specifications
Main-circuit
power
WSDV-2R8
WSDV-5R0
WSDV-6R8
Single/3-phase 200V～240V
10%
15%


50/60Hz
WSDV-110
3-phase 200V～240V
10%
15%


50/60Hz
Control
circuit power
Signle phase 200V～240V
10%
15%


50/60Hz
Encoder
feedback
17-bit(131072 resolution)7-wire serial absolute encoder;
20-bit(1048576 resolution)5-wire serial incremental encoder;
2500-wire(10000 resolution)ABZ incremental encoder.
