Weil-McLain 88 - Boiler Dimensions and Tappings

Weil-McLain 88 Water and steam boilers — Series 2 — for Gas, Light Oil, & Gas/Light Oil-Fired Burners
36 Part No. 550-100-068/1009
Dimensions
Dimensions (inches)
Model A B C D E L W H
488
23 — — 10 54 ¾ 34 ¾ 30
23 6
588
31 — — 10 54 ¾ 42 ¾ 38
31 6
688
39 — — 10 54 ¾ 50 ¾ 46
39 6
788
47 — — 12 53 ¾ 58 ¾ 54
47 6
888
55 — — 12 53 ¾ 66 ¾ 62
55 6
988
63 — — 14 52 ¾ 74 ¾ 70
63 6
1088
71 — — 14 52 ¾ 82 ¾ 78
71 6
1188
79 — — 14 52 ¾ 90 ¾ 86
79 6
1288
87 39 ½ — 14 52 ¾ 98 ¾ 94
87 6
1388
95 47 ½ — 14 52 ¾ 106 ¾ 102
95 6
1488
103 55 ½ — 16 51 ¾ 114 ¾ 110
103 6
1588
111 63 ½ — 16 51 ¾ 122 ¾ 118
111 6
1688
119 47 ½ — 16 51 ¾ 130 ¾ 126
119 6
1788
127 31 ½ 79 ½
1656" x 19(6"
oval
51 ¾ 138 ¾ 134
127 6
1888
135 39 ½ 87 ½ 51 ¾ 146 ¾ 142
135 6
Model 3UPPLYRETURNTAPPINGS "URNERLENGTHS$IMENSION&
Supply tappings (No. & size) Return tappings (No. & size) Carlin Riello Power-
Flame
Beckett
Oil
Beckett
Gas
Steam Water Steam Water
488R
2 – 5" 2 – 5" 1 – 6" 1 – 6" 21 33 31 21 29
488
2 – 5" 2 – 5" 1 – 6" 1 – 6" 21 33 31 21 30
588
2 – 5" 2 – 5" 1 – 6" 1 – 6" 21 33 31 21 30
688
2 – 5" 2 – 5" 1 – 6" 1 – 6" 21 33 34 22 30
788
2 – 5" 2 – 5" 1 – 6" 1 – 6" 21 33 34 22 30
888
2 – 5" 2 – 5" 1 – 6" 1 – 6" 21 49 34 22 30
988R
2 – 5" 2 – 5" 1 – 6" 1 – 6" 21 49 34 22 30
988
2 – 5" 2 – 5" 1 – 6" 1 – 6" 26 49 34 22 30
1088R
2 – 5" 2 – 5" 1 – 6" 1 – 6" 26 49 34 22 30
1088
2 – 5" 2 – 5" 1 – 6" 1 – 6" 26 49 34 22 30
1188
2 – 5" 2 – 5" 1 – 6" 1 – 6" 26 49 39 23 30
1288
3 – 5" 2 – 5" 1 – 6" 1 – 6" 26 49 39 23 30
1388
3 – 5" 2 – 5" 1 – 6" 1 – 6" 26 49 39 23 30
1488
3 – 5" 2 – 5" 1 – 6" 1 – 6" 26 49 39 — 30
1588
3 – 5" 2 – 5" 1 – 6" 1 – 6" — 49 39 — —
1688R
3 – 5" 2 – 5" 1 – 6" 1 – 6" — 49 39 — —
1688
3 – 5" 2 – 5" 1 – 6" 1 – 6" — 49 39 — —
1788
4 – 5" 2 – 5" 1 – 6" 1 – 6" — 49 44 — —
1888
4 – 5" 2 – 5" 1 – 6" 1 – 6" — 56 44 — —
