Weil-McLain CGi 4 Series - Base

Part Number 550-142-302/0520
CGi
SERIES 4 — GAS-FIRED WATER BOILER — Boiler Manual
64
Replacement parts — base
12c
Figure 40 Base assembly
Item Description
Weil-McLain
part number
Base assembly kit
(includes base panels items 1, 2, 3, 4, 5, 6 and 7)
CGi-25 & CGi-3
CGi-4
CGi-5
CGi-6
CGi-7
CGi-8
381-354-337
381-354-338
381-354-339
381-354-340
381-354-341
381-354-342
1
Base side panel (in Base assembly)
2
Base front cross-tie assembly (in Base assembly)
3
Base back cross-tie assembly (in Base assembly)
4
Burner shield (in Base assembly)
5
Base pan angle, left side (in Base assembly)
6
Base pan angle, right side (in Base assembly)
7
Base pan (in Base assembly)
7a
Base pan air baffle (in Base assembly)
8a
Burner mounting plate
CGi-25 & CGi-3
CGi-4
CGi-5
CGi-6
CGi-7
CGi-8
450-003-690
450-003-691
450-003-692
450-003-693
450-003-795
450-003-796
8b
Rear spacing strip
CGi-25 & CGi-3
CGi-4
CGi-5
CGi-6
CGi-7
CGi-8
550-320-160
550-320-161
550-320-162
550-320-163
550-320-164
550-320-165
8c
Nut, hex 5mm Zp
550-320-170
9
Base insulation kit
CGi-25 & CGi-3
CGi-4
CGi-5
CGi-6
CGi-7
CGi-8
381-354-330
381-354-331
381-354-332
381-354-333
381-354-334
381-354-335
10
Boiler leg kit
550-320-219
11
Manifold
CGi-25 & CGi-3
CGi-4
CGi-5
CGi-6
CGi-7
CGi-8
591-126-735
591-126-736
591-126-737
591-126-738
591-126-739
591-126-740
12
Main burner orifice — Natural gas, sea level (see Table 2, page 12 for
orifice size) CGi-25
CGi-3 - CGi-5
CGi-6 - CGi-8
Main burner orifice — Liquefied Petroleum (Propane) gas, sea level
(see Table 2, page 12 for orifice size)
CGi-25
CGi-3 - CGi-5
CGi-6 - CGi-8
560-529-090
560-529-126
560-529-077
560-529-084
560-529-111
560-529-078
13
Burner
512-200-076
14
Screw, 10-32 x
.
0.38 STP type 23 hex, washer head slot
562-135-710
15
Rollout thermal fuse element
512-050-230
