Part number 550-100-270/0122
9
ECO
®
Tec series 2 gas-fired water boiler – boiler manual



With the optional floor standing pedestal kit, the boiler is
approved for installation on combustible ooring, but must never
be installed on carpeting.
Do not install boiler on carpeting even if foundation
is used. Fire can result, causing severe personal
injury, death or substantial property damage.

1. Provide a solid foundation pad, at least 2 inches above the
oor, if any of the following is true:
oor can become ooded,
e oor is dirt, sand, gravel or other loose material,
e boiler mounting area is severely uneven or sloped.
2. e minimum foundation size is:
ECO Tec: 20 inches wide x 20 inches deep.
3. Foundation may be of wood, brick or concrete (minimum
2 inches thick) construction.
If ooding is possible, elevate boiler suciently to prevent
water from reaching boiler.

The boiler is heavy. Use caution not to drop
the boiler or cause bodily injury while lifting
and handling. Verify that the boiler is securely
attached to prevent possibility of boiler falling aer
installation.
After the boiler is removed from the shipping
carton, DO NOT allow the boiler to sit on its
bottom. is would cause pressure on protruding
plastic, resulting in interior damage. Either lay
the boiler on its back or leave on the styrofoam
protective shipping base.
Do not drop boiler or bump jacket on oor or pallet.
Damage to boiler can result.
Cold weather handling — If boiler has been
stored in a very cold location (below 0°F) before
installation, handle with care until the plastic
components come to room temperature.
1. The ECO Tec boiler is generally easier to handle and
maneuver aer removing the shipping container.
2. Remove Items1, 2, 3, 4, and 6 in Figure3. Remove trim kit
and parts from Item4.
3. Leavetheboilerrestingonthestyrofoamprotective
base (Item7) and bottom cardboard cap (Item8), until ready
to place on the wall. If removing the boiler from the shipping
base, rest the boiler on its back, NOT on its bottom.
Failure to comply with the procedure given could
result in severe personal injury, death or substantial
property damage.
1 Cardboard cap, top
2 Cardboard angles
3 Pad
4 Styrofoam protective cap
5 Boiler
6 Cardboard sleeve
7 Styrofoam protective base
8 Cardboard cap, bottom

Figure3 Boiler shipping container
ECOTec
Boiler
Model
HeatingOnly Combi
Without
Pedestal
lbs.
With
Pedestal
lbs.
Without
Pedestal
lbs.
With
Pedestal
lbs.
80/110 141 163 152 174
150 162 184 172 194
199 178 200 187 209
Table1 Boiler operating weights
