SERVICE TECHNICIAN ONLY — read and follow completely.
Dimensions (continued)
Table 9 Dimensions
BOILER MODEL
NUMBER
B L
Inches mm. Inches mm.
WGO-2 10 1/2 266.7 13 3/4 349.2
WGO-3 13
1/2 342.9 16 7/8 428.7
WGO-4 13 5/8 345.9 16 7/8 428.7
WGO-5 16
7/8 428.7 20 508.0
WGO-6 20 508 23 1/8 587.2
WGO-7 23
1/8 587.2 26 1/4 666.7
WGO-8 26
1/4 666.7 29 31/32 746.2
WGO-9 29
3/8 746.2 32 1/2 825.5
Part number 550-141-826/1014
41
GOLD
WGO
OIL-FIRED NATURAL DRAFT WATER BOILER — SERIES 3 — Boiler Manual
