4-16 Weinig Tools Tech. Dok. / WNW 850 02 / 02.2005.A / © MICHAEL WEINIG AG
Hydraulic clamping
4.3.8 Profile depth, projection, max. cutting circle:
The following table illustrates the relationship between
profile cutterhead, fitted cutter height, resultant profile
depth and maximum permissible cutting circle diameter.
4.3.9 Grinding
The blanks are profiled in accordance with a profile
template and ground in the profile cutterhead on a
Weinig grinder for profiled cutters.
4.3.10 Technical data
– Tool body of high-strength steel
– For 4, 6 or 8 profiled cutters 8 or 10 mm thick, with
serrated back
– Optionally fitted with HSS, stellite or carbide
– Blank weight max. 50 g per 10 mm blank length
– Positive clamping of the profiled cutters with serrated
back, serration 1/16" x 60°
– Hardened clamping elements with ground clamping
area
– Cutting angle: 12° or 20°
– Cutting circle diameter: 137 mm, 150 mm or 163 mm
– Max. speed: n = 6,000 rpm
for dia. 137 mm and 163 mm
– Max. speed: n = 8,000 rpm
for dia. 150 mm
– Applies for a maximum cutter projection of 36 mm.
Subject to change without notice!
Cutter height
[mm]
Max. permissible cutting circle dia. [mm] for
profile cutterhead dia. [mm]
Max. possible
profile depth
[mm]
137 150 163
50 170 185 200 approx. 11
60 190 205 220 approx. 20
70 210 225 240 approx. 30
