Plaza Viva | 120996-0000 | v2.4 | 2017-07-12 weinor GmbH & Co. KG
List of contents
General
Intended use
Plaza Viva is a sun protection awning that can primarily* be used for this
purpose. Misuse of the awning, as well as any alterations, changes or
additions to the awning that are carried out without weinor‘s written
permission can lead to damage, hazards or the collapse of the awning.
These are not permitted and will result in the voiding of the guarantee
claims.
(* The Plaza Viva can be used with a pitch of >7° or with the telescopic post option as rain
protection (= no risk of pooling). Caution! If the awning fabric is retracted while still wet, mould
and stains may form! Only retract a wet awning in the event of an emergency (e.g. with the risk of
a storm, frost or snowfall)! Wet fabric must be dried out as quickly as possible when the awning
is open!
CE mark
Weinor GmbH & Co. KG declares that the
Plaza Viva is in compliance with the basic
requirements and relevant provisions
of the EN standards. Plaza Viva meets
the requirements of the wind resistance
class indicated in the CE conformity
marks. The requirements shall only be
deemed as having been met once the
manufacturer‘s instructions have been
adhered to.
Noise level
In the non-assembled state, the noise level of this awning is below 70
dB(A).
Symbols used
Note/Tip
Read instructions,
observe details
"CORRECT" "INCORRECT"
Power OFF Power ON
Function check/
visual inspection/
check
Professional
maintenance /repairs
(by specialist retailer)
2
Action step/necessary action
For your safety
Safety symbols
Warning! Risk of electric shock
"Danger" of electric shock
Danger level III
Warning! Personal injury
"Danger" of personal injury.
Danger level
II
Caution! Product and property damage
Danger level
I
Safety instructions
Warning! Danger of electric shock due to impro-
per handling of electric components!
• Follow the installation instructions of the included electric compo-
nents!
• Work on electrical fixed installation is only permissible when con
-
ducted by electrically skilled persons according to VDE 100!
Careful! Personal injury can result from improper
operation and use of the construction!
• It must be assured that no children or people unable to properly
assess the risks of improper or incorrect use are permitted to
operate the awning.
• Always keep the remote radio control out of reach of children!
• Observe the instructions as well as the regulation and operating
instructions of the manufacturer of the drive, switch or control
devices!
• The space needed for the awning to open must always be kept
clear. There is a risk of people being crushed in this space!
• For cleaning, disconnect the power supply (switch off fuses) and
switch off automatic control system when working in the move
-
ment range of the construction in order !
• Do not lean ascending aids (e.g. ladders) against the construction!
• Do not lean any articles (e.g. gardening devices) against the cons
-
truction!
• Do not hang any articles (e. g. lamps, leads etc.) on the awning!
• Do not use any sun or wind sensors if you use the telescopic post
or Valance Plus vertical shading!
Caution! Personal injury / material damage can
result from improper use and operation of the
construction!
• Use the construction for sun protection only!
• Do not use the construction in case of rain or frost!
• Do not use the construction in strong winds (see wind resistance
class)!
• Observe the wind resistance class of the construction in order top
prevent the damage to the awning caused by wind!
• Adjust the automatic system control to manual operation in your
absence to prevent automatic operation of the construction. The
automatic system control may fail under extreme conditions e.g.
power failures, defects or sudden storms (danger that the awning
could be damaged or fall down).
• If there is a risk of frost, rain or storm, the awning system must
be switched from automatic to manual control to prevent it from
moving automatically
• Retract the awning in case of frost, rain or portending storm.
• Follow the cleaning instructions in order to prevent damage to
the construction due to erroneous or incomplete cleaning or due
tio improper cleaning agents.
• Adhere to the maintenance instructions/maintenance intervals.
• Only use spare parts which have been approved by the manufac
-
turer!
Weinor GmbH & Co. KG
Mathias-Brüggen-Straße 110
50829 Cologne (Germany)
17
EN 13 561
Awning for use in
exterior area
Wind resistance class:
Class 3
General 4
For your safety 4
Use of the Plaza Viva 6
Explanation of wind resistance classes (DIN EN 13561) 6
Operation of the Plaza Viva 7
Lowering / winding up the telescopic post again (option) 8
Operation Volant Plus (Option) 9
Operating instructions to protect against personal injury and damage to property
10
Cleaning 12
Maintenance 13
Disassembly and Disposal 14
Rectifying faults 15
Product Overview 16
