Analogue module EM3/3
3 Product description
83295402 1/2019-01 La
6-16
3 Product description
3.1 Inputs and outputs
The degree of modulation can be controlled via a control signal, which is connec-
ted to the input of the analogue module EM3/3.
The current degree of modulation can be signalled via an output from the analogue
module EM3/3.
3.1.1 Input
The analogue module EM3/3 has an analogue input.
The input can be set for the following ranges using a DIP switch:
current input 0…20mA or 4…20mA, depending on the range set,
voltage input 0…10V or 2…10V, depending on the range set.
3.1.1.1 Gas burner / dual fuel burner gas operation
Degree of modula-
tion
0…20mA 4…20mA 0…10V 2…10V
0% 0mA 4mA 0V 2V
10% 2mA 5.6mA 1V 2.8V
20% 4mA 7.2mA 2V 3.6V
50% 10mA 12mA 5V 6V
100% 20mA 20mA 10V 10V
3.1.1.2 Oil burner / dual fuel burner oil operation
Degree of modula-
tion
0…20mA 4…20mA 0…10V 2…10V
Stage1 <5mA <7.8mA <2.5V <4V
Stage2 >15mA >16mA >7.5V >8V
