Installation and operating instruction
Analogue module EM3/3
3 Product description
83295402 1/2019-01 La
7-16
3.1.2 Output
The analogue module EM3/3 has two analogue outputs.
The outputs can be set for the following ranges using DIP switches:
current output 0…20mA or 4…20mA, depending on the range set,
voltage output 0…10V or 2…10V, depending on the range set.
3.1.2.1 Gas burner / dual fuel burner gas operation
Degree of modula-
tion
0…20mA 4…20mA 0…10V 2…10V
0% 0mA 4mA 0V 2V
10% 2mA 5.6mA 1V 2.8V
20% 4mA 7.2mA 2V 3.6V
50% 10mA 12mA 5V 6V
100% 20mA 20mA 10V 10V
3.1.2.2 Oil burner / dual fuel burner oil operation
Output1
The values outside of control mode and stage1 are identical.
Degree of modula-
tion
0…20mA 4…20mA 0…10V 2…10V
Outside of control
mode
0mA 4mA 0V 2V
Stage1 0mA 4mA 0V 2V
Stage2 20mA 20mA 10V 10V
Switch off point St2
running closed
14mA 15.2mA 7V 7.6V
Switch on point St2
running open
16mA 16.8mA 8V 8.4V
Output2
The values outside of control mode and stage1 are different.
Degree of modula-
tion
0…20mA 4…20mA 0…10V 2…10V
Outside of control
mode
0mA 4mA 0V 2V
Stage1 10mA 12mA 5V 6V
Stage2 20mA 20mA 10V 10V
Switch off point St2
running closed
14mA 15.2mA 7V 7.6V
Switch on point St2
running open
16mA 16.8mA 8V 8.4V
