Weishaupt EM3/3 - Technical Data

Installation and operating instruction
Analogue module EM3/3
3 Product description
83295402 1/2019-01 La
8-16
3.2 Technical data
3.2.1 Electrical data
Input
Voltage input 0/2V…10V
Input impedance 200kΩ
Current input 0/4mA…20mA
Input impedance 500Ω
Output
Voltage output 0/2V…10V
Internal resistance of source 83Ω
External impedance min 12 kΩ
Current output 0/4mA…20mA
Internal resistance of source 100Ω
External impedance 0.5 …2.2kΩ
