25
6
Maximum achievable swimming pool
temperature. The solar pump is
switched off once this temperature is
reached, if the passive collector
protection is switched off (setting
collector protection: 0, 2 or 4).
Variation: 20
Setting range: 20°C…95°C
Presetting: 35°C
Swim pool
Temp.
Maximum
35°C
Swimming pool temp. setpoint initiates
the shutdown of swimming pool loading.
Variation: 20
Setting range: 0°C…90°C
Presetting: 30°C
Swim pool
temp.
Setpoint
30°C
Release level for external heating
appliance via MFA contact.
Variation: 1
Setting range: 0°C…70°C
Pre-setting: 40°C
Tank
Temp.
Minimum
40.0°C
When the average pump speed reaches
50% the calorifier Temp.
Setpoint is reduced by this amount.
Example: 60°C – 15K = 45°C
When the calorifier actual temperature
reaches the reduced value (45°C), the
MFA contact is activated.
Variation: 12
Setting rnage: 0K…40K
Presetting: 15K
Diff.
calorifier
Minimum
15.0K
Switch signal level for external heating
appliance (18hrs.), only possible on hot
water storage tank .
Variation: 1
Setting range: 0°C…70°C
Presetting: 55°C
Tank
temp.
Setpoint
55.0°C
Switch signal level for external heating
appliance or for calorifier load pump.
Variation: 12,48
Setting range: 0°C…90°C
Presetting: 70°C
Calorifier
temp.
Setpoint
70.0°C
Change setting continued
Temperature differential between
return sensor (THR) and calorifier
sensor “top” (TPO), at which the
three way valve (VRA) is de-energised.
Variation: 15
Setting range: 0 K…40 K
Presetting: 2.0 K
Return
Diff.
Off
2.0K
Maximum achievable swimming pool
temperature. The solar pump is
switched off once this temperature is
reached, even if the passive collector
protection is switched on (setting
collector protection: 1, 3 or 5).
Variation: 20
Setting range: 20°C…95°C
Presetting: 40°C
Swim pool
Temp.
Protection
40.0°C
