Weishaupt WRSol 1.0 Installation And Operating Instructions

3
Contents
1 Safety instructions 5
2 About the Weishaupt solar controller WRSol 1.0 6
2.1 What does the solar controller do 6
2.2 What you have to observe 6
3 Installation and connection 7
3.1 Included in delivery 7
3.2 Wall mounted installation 7
3.3 Commissioning 8
3.4 Electrical connection 9
4 Hydraulic variations 11
4.1 Variation 1 11
4.2 Variation 12 11
4.3 Variation 15 12
4.4 Variation 20 12
4.5 Variation 48 13
5 Operation 14
5.1 Display and operating elements 14
5.2 Navigation / menu structure (change hydraulic variation) 14
5.3 Where do I find what… 15
5.4 Display 18
6 Parameters 20
6.1 Select type of operation 20
6.2 Select temperature and values 21
6.3 Change settings 23
6.4 Test outputs 28
6.5 Select options 29
6.6 Display faults 30
6.7 Language selection 30
7 Functions 31
7. 1 C o l l ector protection 31
7. 2 Energy management via the MFA output 32
7. 3 Fault transmission 32
7. 4 Pump standby protection 33
7. 5 Reference value of pump speed control
in conjunction with collectors 33
7. 6Pump control in conjunction with a solid fuel boiler 34
7. 7 Solid fuel boiler functions 35
7. 8Manual operation 36
7. 9Calculation of energy yield 36
7.10 Start aid function 36
1
2
3
4
5
6
7

Weishaupt WRSol 1.0 Specifications

General

Brand	Weishaupt
Model	WRSol 1.0
Category	Controller
Language	English
