3.3 Commissioning
The WRSol 1.0 is constructed in such a way, that the
function of the controller and the type of setting
parameters can be set by selecting the relevant hydraulic
variation.
Only the selection menus and setting parameters required
for the hydraulic variation selected will then be displayed.
All other parameters are blanked out.
Procedure:
1. Select hydraulic variation required.
➭ Ch. 4
2. Carry out electrical connection in accordance with
the hydraulic variation selected.
➭ Ch. 3.4
3. Program the controller, if necessary, start with
language selection.
➭ Ch. 6.7
4. The the hydraulic variation selected under item one in
the controller.
➭ Ch. 6.3
5. Activate overheat protection (recommendation).
➭ Ch. 6.5
6. Select all temperatures and values and check their
plausibility.
➭ Ch. 6.2
7. Test and check all outputs in type of operation Manual
(the pump start of the solar pumps is not possible
above collector temperatures of 130°C, not even in
manual operation).
➭ Ch. 6.4; Ch. 7.8
8. The controller is reset to type of operation Auto.
➭ Ch. 6.1
9. Complete commissioning log in appendix.
10. Show customer the operation and functions of the
controller.
