DIAGNOSTICS | 11.3 Error messages
13 Error 4
Movement timeout
Set time (x) ms
Time monitoring for the
cycle has been triggered.
Check if mechanical com-
ponents run smoothly
Check feedback of the sen-
sor signal
Resetting the monitoring of
the movement timeout via
the dynamics page of the
Web interface
14 Error 5
Motor contactor switched
under load
The motor contactor was
switched during move-
ment.
Check electrical connec-
tion of the motor contactor
15 Reserve - - - -
16 Error 4
Error during execution of the measuring cycle quick
stop
Cause: (1...12)
-
1
The rotary indexing table is not on the sensor at the
start of the measuring cycle quick stop
To ensure a proper direc-
tion specification at the start
of the measuring cycle
quick stop, the rotary inde-
xing table has to be on the
sensor at the start.
2
During oscillating mode, the rotary indexing table has
not yet reached the constant movement phase as it
leaves the sensor.
The measured start ramp
time on the sensor is too
long. Please check the
setup of the mechanics and
the connection of the motor
Contact WEISS GmbH
3
End of the measurement data field reached
Increase upper limit nomi-
nal frequency, parameter
set 1
Contact WEISS GmbH
4
During the measurement of the quick stop ramp, the
calculation of the start value for the quick stop ramp
could not be ended on time.
Repeat the measurement.
In case the fault persists:
Contact WEISS GmbH
5
During measuring of the dynamic parameters on the
sensor, the rotary indexing table has not yet reached
the constant movement phase as it leaves the sensor.
Reduce start ramp time,
parameter set 1
6
The start/stop ramp time cannot be increased any fur-
ther during measuring of the dynamic parameters on
the sensor.
Increase upper limit start/
stop ramp time, parameter
set 1
Contact WEISS GmbH
7
The brake ramp time cannot be increased any further
during measuring of the quick stop ramp.
Increase upper limit stop
ramp time, parameter set 1
Contact WEISS GmbH
Event
number
Category Reaction Event text Cause Remedy
