GENERAL USE AND SAFETY INFORMATION
Thank you for purchasing this quality DIGITAL HEAT TRANSFER CONTROLLER by Weiss.
This digital controller has been designed to ensure highly effective transfer of heated air throughout your
home. The large screen is designed for easy and straightforward setup of your heat transfer system, using a
high precision built-in sensor with custom sensing algorithm to accurately determine room temperature and
improve system stability.
NOTE: THESE UPDATED INSTALLATION AND OPERATION INSTRUCTIONS SUPERSEDE ANY INSTRUCTIONS ON THE
CARTON or other FITTING INSTRUCTIONS
PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE COMMENCING INSTALLATION.
Note: Pictures and diagrams on packaging are designed only to be used as a concept. All installation
details should be carried out as per the instructions herein.
Note: THIS PRODUCT MUST BE WIRED BY A REGISTERED ELECTRICIAN
SUITABILITY
The controller constantly monitors the room and set temperatures. When the heat source provides heat to
the room and raises the room temperature above the set temperature, the controller will detect this increase
and turn the fan on.
BEFORE YOU START
Weiss DIGITAL HEAT TRANSFER CONTROLLER must not be mounted in areas subject to direct splashing. Refer
to New Zealand standard NZECP2: 1988 Section 4.6 and Australian Standard AS3000:1991, Section 6.2.
SAFETY NOTE
This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety. Children should be
supervised to ensure that they do not play with the appliance.
To avoid a hazard, a damaged supply cord must be replaced by the manufacturer. This includes the
removal of the supply cord as this appliance is supplied as compliant. Modification including removal of
the plug or cutting of the supply cord (fitted to any motor) will render the unit NON-COMPLIANT.
INSTALLATION INFORMATION
IMPORTANT
Selecting the mounting location
• The controller is for internal use only.
• Mount approx. 1.5 metres above the floor on an inner wall near the heat source.
• The controller must be placed within the same room as the heat source.
• Avoid locations which are not affected by the heat source, e.g. other side of the room or around a
corner.
• Do not mount on hot surfaces or surfaces exposed to direct sunlight.
FOR OPTIMUM PERFORMANCE – Installation Instructions
1. Open the controller by placing your thumb on the bottom edge of the thermostat unit and using
your other fingers to apply pressure to the rear portion of the unit. Sliding the rear portion toward
your thumb will expose the mounting holes.
2. Choose a mounting position on the wall and cut a 64 mm diameter hole in the wall gib,
avoiding any structure timber framing or wiring contained behind.
3. See Wiring Diagram below to connect the fan.
4. After connecting the required wiring, mount the base of the controller with the 2 screws, noting the
direction of the display is correct.
5. Reconnect the interconnect cable to the display front.
