Part Number 000016034 Rev 00 07/19 17
Section 2 Installation Instructions
Maximum Breaker Size & Minimum Circuit Amperage Chart
Important
Due to continuous improvements, this information is for reference only. Please refer to the ice machine serial number tag to
verify electrical data. Serial tag information overrides information listed on this page.
Series Ice
Machine
Voltage
Phase
Cycle
Air-Cooled Water-Cooled QuietQube
Max
Fuse/
Circuit
Breaker
Min
Circuit
Amps
Total
Circuit
Amps
Max
Fuse/
Circuit
Breaker
Min
Circuit
Amps
Max
Fuse/
Circuit
Breaker
Total
Circuit
Amps
UF244 230/1/50 10 Amp N/A 2.7 N/A N/A — —
UN0200 230/1/50 10 Amp N/A 2.7 N/A N/A — —
UF0200 230/1/50 10 Amp N/A 2.7 N/A N/A — —
UF0350 230/1/50 10 Amp N/A 3.3 N/A N/A — —
UN0300 230/1/50 10 Amp N/A 3.3 N/A N/A — —
UF0388 230/1/50 10 Amp N/A 3.3 N/A N/A — —
UF0399 230/1/50 10 Amp N/A 3.3 N/A N/A — —
RF0320 230/1/50 20 Amp 12.8 N/A N/A N/A — —
RN0320 230/1/50 20 Amp 12.8 N/A N/A N/A — —
RN0620 230/1/50 25 Amp 16.3 N/A 25 Amp 15.4 — —
RF0620 230/1/50 25 amp 16.3 N/A 25 Amp 15.4 — —
RN1100 230/1/50 15 Amp 11.7 N/A 15 Amp 11.2 — —
RF1300/RF1220 230/1/50 15 Amp 11.7 N/A 15 Amp 11.2 10 Amp 1.4
RF2500 400-415/3/50 16 Amp 13.9 N/A 16 amp 13.9 — —
RF2200 230/1/50 — — N/A — — 15 Amp 3.2
RF1279R 208-230/1/60 15 Amp 1.4 N/A — — — —
RF2379R 208-230/3/60 15 Amp 3.2 N/A — — — —
NOTE: Maximum allowable voltage variation at compressor start-up is ±10% of voltage listed above and on the model/serial
plate.
QUIETQUBE REMOTE CONDENSING UNIT
Condensing Unit Voltage/Phase/Cycle Maximum Fuse/Circuit Breaker Minimum Circuit Amps
RCUF1200
208-230/60/1 15 15
208-230/60/3 15 15
RCUF1000
208-230/60/1 15 15
208-230/60/3 15 15
RCUF2200 208-230/60/3 15 15
