Welch Allyn Atlas Operator's Manual

57
Advanced Configuration Menu Settings
Advanced Configuration Item Possible settings Factory
default
Language English, French, Canadian French,
Spanish, German, Portuguese, Italian,
Chinese, Japanese
English
Silence duration 60, 90, or 120 seconds 90 seconds
ECG gain automatic, or 10mm/mV automatic
ECG lead set 3 wire or 5 wire 3 wire
ECG speed 6.25, 12.5, or 25 mm/s 25 mm/s
ECG bandwidth Monitor or Extended Monitor
Initial pressure 120, 140, 160, 180, 200, 240, 280 mmHg 160 mmHg
MAP
or
Alternate BP field (when language
setting is configured to Chinese only)
Yes or No
MAP, kPa, or nothing
No
Second trace selection (621xx) ECG or SpO
2
ECG
Second trace selection (622xx) ECG, SpO
2
or Respiration ECG
Second trace selection (623xx) ECG, SpO
2,
Respiration or CO
2
CO
2
Temperature units (622xx and 623xx) ºF or ºC ºF
Respiration speed (622xx and 623xx)
12.5, 6.25, 3.125 mm/s 6.25 mm/s
CO
2
units (623xx) mmHg, %, or kPa mmHg
Print On Alarm (on models with
printers)
Yes or No No
