6 / MAINTENANCE
7 / TROUBLESHOOTING
The helmet and ADF must be checked regularly. Defective equipment should not
be used. Parts that are broken, missing, worn, distorted or contaminated, should be
replaced immediately.
a. Inspect lenses frequently. Immediately replace any scratched, cracked, or pitted
lenses as they may impair visibility and reduce protection.
b. Inspect Helmet Shell and Harness Assembly frequently. Replace any damaged or
worn components immediately.
c. Keep the Sensors and the Solar Panel clean at all times. When cleaning the Welding
Helmet or Filter Lens do not use solvents or abrasive cleaning agents. Clean with a
soft cloth after use.
FAU LT POSSIBLE CAUSES POSSIBLE REMEDY
The Filter Lens does not
activate at all (fails to darken)
Weld/Grind switch is switched to
‘Grind’
Switch to ‘Weld’
Batteries are discharged Replace Batteries
Batteries are not tted correctly Check batteries (see section 4)
Battery or terminals are dirty Inspect & clean battery/terminals
The Filter Lens ickers or
intermittently fails to darken
Front Cover Lens is dirty or
scratched & is obstructing the
sensors
Replace cover lens
Sensors are dirty Clean the Sensors with a soft cloth
Sensitivity too low Increase sensitivity level
Momentary disruption to sensing
of the arc
Increase delay time adjustment (will
help compensate for
momentary disruptions)
Filter lens is dark when no arc
is present or stays dark after
the weld is extinguished
Ambient light level is too bright
Reduce the ambient light level in
the area
Sensitivity too high Reduce sensitivity level
Batteries discharge very
quickly
Lens is being activated by other
light sources when not in use.
Switch to ‘Grind’ when not in use.
