Weldex WDRV-5063M - System Wiring Details; Pin Connection Details

[
General Camera
]
Audio Input
(
White
)
Video Input
(
Yellow
)
RCA Jack
(FEMALE)
WDRV-5063M/7063M
System Wiring. 11
4
3
5
6
2
1
HOLE
Pin No.
1
2
3
4
5
6
Description
VIDEO
DC +12V
MORTOR +
AUDIO
MORTOR -
GND
WDRV-3478C Pin Connection
[
SIDE VIEW CAMERA
]
WDRV-7063C Pin Connection
[
REAR VIEW MOTORIZED CAMERA
]
FEMALE
B
4
3
21
HOLE
Pin No.
1
2
3
4
Description
S/D
(
GND
)
AUDIO
VIDEO
DC +12V
FEMALE
A
Power
DC +12~32V
GND
Trigger1
Power
DC +12~32V
GND
MALE
(
Camera Input
)
The shutter camera is optional.
WDRV-5041M/7041M
WDRV-5061M/7061M
4 Pin Locking Cable
6 Pin Locking Cable
[
WDL-5001M / 7001M
]
[
WDRV-5041M / 7041M
]
[
WDRV-5061M / 7061M
]
Bracket for fixing cable.
(
Option
)
Bracket for fixing cable.
(
Option
)
