Technical Data
soldering station
WX 1
soldering station
WX 2
desoldering station
WXD 2
Hot air station
WXA 2
Dimensions L x W x H 170 x 151 x 130 mm
6,69 x 5,94 x 5,12 inch
Weight ca. 3,2 kg ca. 3,2 kg ca. 3,8 kg ca. 3,8 kg
Mains supply voltage 230 V, 50 Hz / 120 V, 60 Hz / 100 V 50/60 Hz
Power consumption 200 W 200 W (255 W) 200 W (255 W) 200 W (255 W)
Safety class I, antistatic housing
III, Soldering tool
Fuse T2 A (230 V)
T4 A (120 V)
Temperature range
Tool dependent
100 - 450°C (550°C)
200 - 850°F (999°F)
Temperature accuracy ± 9 °C / ± 17 °F
Temperature stability ± 2 °C / ± 4 °F
Air consumption - 35 l / min, max vacu-
um 55 kPA (8 psi)
-
Compressed air connection - Compressed air
hose outer diameter
6 mm (0,24“)
Compressed air hose
outer diameter 6 mm
(0,24“)
Compressed air - Inlet pressure 400 -
600 kPA
(58-87 psi); oil-free,
dry compressed air
Inlet pressure 400 -
600 kPA
(58-87 psi) oil free,
dry compressed air or
nitrogen (N2) *
Air ow: - approx. 0-18 l/ min at
6 bar
* WXA 2: Nitrogen N2 reduces oxidation and ux remains active for longer. We recommend the nitrogen N2 that is available in
steel bottles. The bottle must be equipped with a 0-10 bar pressure reducer.
Subject to technical alterations and amendments.
GB
ENGLISH
