M011C.02 2M-Z16298 Owners Manual for Built-In Well Modular Warmers
PARTS LIST: M400-427 SERIES
21
Model: Modular Warmers M400-427T, TD, TDM, TDMAF, M400-427E, CE, ED, EDM, EDMAF
Fig No Part No Description Qty Application
17
2T-38968 THERMO K TYPE
4
T-STAT UNITS
2T-46551 THERMO CTRL 96IN CAP T-STAT UNITS w/ 96IN CAPILLARY
2T-45917
THERMO CTRL W/AUX
WARMERS
T-STAT UNITS, AUTOFILL
2E-30570 SWITCH INFINITE, 120V
4
INFINITE UNITS, 120V
2E-30562 SWITCH INFINITE, 240V INFINITE UNITS, 240V
18
2R-44373
KNOB CONTROL ASSY
WARMERS
4
INFINITE UNITS
2R-40498 KNOB ASSY MOD 100DT T-STAT UNITS
20 2E-46529 SOLENOID VALVE 1/4NPT 240 1 AUTOFILL UNITS
21
P2-40843 BRKT MTG THERMO INFINITE 2 T-STAT (SPLIT CONTROL)
P2-48176 BRKT THERO MOD200TDM AUT 1 MOD400TDMAF(6), MOD427TDMAF
P2-48285 BRKT THERMO MOD400 1 M400-427 T-STAT, DRAIN, MANIFOLD, AUTOFILL
22 2E-306865 CONTROL LIQ LEVEL 208/240 1 AUTOFILL UNITS
23 2I-40034 GROMMET SCREW T4 4 AUTOFILL UNITS
24 2K-33996X FTG FLEX CONDUIT 90X3/8 2
25 2I-Z12311 GASKET-FIBER WASHER 2
26
P2-300712 COVER BOT M227-427TDM/AM 2 M427E, MOD427TDM (AF)
P2-35004 COVER BOTTOM 200 SERIES 2 M400
27 P2-303359 SHROUD SIDE MODS ROHS 2 M400
28
P2-Z14627 SHROUD, FRONT M4
1
M400, 427, DIGITAL
P2-48192 SHROUD REAR MOD 420 427 M400
P2-303358 SHROUD FRONT MOD 400 427 M400 INFINITE & T-STAT
29 2H-36050 INSUL FG .6 MICRO 1/36 SOLD BY FOOT
30 2H-36196 INSUL FG .6 MICRO 1X45 SOLD BY FOOT
31
P2-WL0082 PAN ELEM ASSY
4
M400 DIGITAL
P2-WL0096 PAN ELEM ASSY MOD 227-527 M427 DIGITAL
WS-503843
KIT PAN ELEM W/ELEMENT
208/240
M400 T-STAT & INFINITE
WS-503840 KIT ELEM PAN W/ELEMENT M427 T-STAT
32
WS-50398 ELEM 240V 1200W M P
4
M400 INFINITE, 240V
2N-303375UL ELEM HEATING 240V 1650W M400 T-STAT, 240V
2N-300706UL ELEM 240V 1650W 12 X 27 M427
33
WS-55707 COVER ELEM MOD WARMER
4
M400, INFINITE UNITS
WS-503842 KIT ELEM PAN W/O ELEMENT M400, T-STAT & DIGITAL
WS-503841 KIT ELEM PAN W/O ELEMENT M427
34 D8-303352 BRKT THERMO BULB 4 THERMOSTAT UNITS
35 P2-WL0081 PAN ELEM ASSY MOD200-500 4 INFINITE 240V
36 WS-50374 THERMO, HI-LIMIT, SFTY, 550F 4 INFINITE UNITS
NI 2C-30397 CLIP ELEM WRMRS SML 36 VARIOUS OLDER UNITS
