M011C.02 2M-Z16298 Owners Manual for Built-In Well Modular Warmers
PARTS LIST: M500-527 SERIES
22
Model: Modular Warmers M500-527T, TD, TDM, TDMAF, M500-527E, CE, ED, EDM, EDMAF
Fig No Part No Description Qty Application
1 P2-31869 SCREEN DRAIN ASSY WARMER 5 DRAIN UNITS
2
P2-Z14636 PAN ASSY 12X20 EAF W/TEE
1
M500 DIGITAL
P2-Z14647 PAN ASSY 12X27 EAF M527 DIGITAL
WS-503893 PAN ASSY 200-500TDM A/F M500 T-STAT & INFINITE
WS-504101 PAN ASSY 12X27 AF M527 T-STAT
3
P2-Z14639 PAN ASSY 12X20 E
5
M500 DIGITAL
P2-Z14637 PAN ASSY 12X20 ED w/DRAIN M500 DIGITAL DRAIN
P2-Z14638 PAN ASSY 12X20 EDM
M500 DIGITAL DRAIN, MANIFOLD
4 M500 DIGITAL DRAIN, MANIFOLD, AUTOFILL
P2-Z14646 PAN ASSY 12X27 EDM
5 M527 DIGITAL, DRAIN, MANIFOLD
4 M527 DIGITAL, DRAIN, MANIFOLD AUTOFILL
WS-55741 PAN W/O DRAIN 200-500 / T
5
M500 T-STAT & INFINITE
WS-53201 PAN W/DRAIN 200-500 /TD M500 T-STAT & INFINITE, DRAIN
WS-55742 PAN W/DRAIN 200-500DM/TDM
M500 T-STAT & INFINITE, DRAIN, MANIFOLD
4 M500 T-STAT & INFINITE, DRAIN, MANIFOLD,AUTOFILL
WS-500700 PAN ASSY 12X27 TDM
5 M527 T-STAT, DRAIN, MANIFOLD
4 M527 T-STAT, DRAIN, MANIFOLD, AUTOFILL
4 2V-35609 VALVE 1 IN GATE BRONZE 1 MANIFOLD UNITS
5 WS-503713 PROBE ASSY, SS AUTOFILL 1 AUTOFILL UNITS
6 2K-48198 ELBOW 3/8 X 90DEG BRASS 1 AUTOFILL UNITS
7 2K-48197 NIPPLE 3/8 NPT X 2 BRASS 1 AUTOFILL UNITS
8 2V-47650 VALVE ANTISYPHON 3/8 1 AUTOFILL UNITS
9 2K-47662 FTG STR BRS 3/8NPT X3/8IN 1 AUTOFILL UNITS
10 2C-46591 CLAMP HOSE 5/8 2 AUTOFILL UNITS
11 2K-31040 BUSHING HEYCO 7/8 OD 1 THERMOSTAT UNITS
12 WS-50131 TERM BLOCK KIT (RETRO 30131) 1 INFINITE & AUTOFILL UNITS
13 2C-41974 NUT 8-32 HEX 7/8 LONG ALU 2 AUTOFILL UNITS
14
2J-35385 LIGHT SIGNAL GLO DOT RED
2
INFINITE UNITS
2J-35687 LIGHT SIGNAL GLO DOT T-STAT UNITS
15
P2-Z12594 PANEL, CONTROL MOD500 TDM
1
M500-527, T-STAT
P2-Z12288 PNL, CNTRL/MOD
MOD500TDMFA(6), MOD527TDMAF(6) (SPLTI)
P2-Z12588 PANEL, CONTROL MOD TDM MOD500TDMFA(6), MOD527TDMAF(6) (SPLTI)
P2-Z12590 PANEL, CONTROL MOD500 M500, INFINITE UNITS
16
P2-48290 BOX OUTLET MOD400 DM TDM
1
M500-527, T-STAT
E7-49046 BOX OUTLET MOD WAR
MOD500TDMFA(6), MOD527TDMAF(6) (SPLTI)
P2-48178 BOX CONTROL MOD AF MOD500TDMFA(6), MOD527TDMAF(6) (SPLTI)
P2-46685 BOX OUTLET MOD 500 M500, INFINITE UNITS
17
2T-38968 THERMO K TYPE
5
T-STAT UNITS
2T-46551 THERMO CTRL 96IN CAP T-STAT UNITS w/ 96IN CAPILLARY
2T-45917 THERMO CTRL W/AUX WARMRS T-STAT UNITS, AUTOFILL
2E-30570 SWITCH INFINITE, 120V
5
INFINITE UNITS, 120V
2E-30562 SWITCH INFINITE, 240V INFINITE UNITS, 240V
