M011C.02 2M-Z16298 Owners Manual for Built-In Well Modular Warmers
PARTS LIST: M500-527 SERIES
23
Model: Modular Warmers M500-527T, TD, TDM, TDMAF, M500-527E, CE, ED, EDM, EDMAF
Fig No Part No Description Qty Application
18
2R-44373
KNOB CONTROL ASSY
WARMERS
5
INFINITE UNITS
2R-40498 KNOB ASSY MOD 100DT T-STAT UNITS
20 2E-46529 SOLENOID VALVE 1/4NPT 240 1 AUTOFILL UNITS
21
P2-48285 BRKT THERMO MOD400 1 M500-527, T-STAT
P2-40843 BRKT MTG THERMO INFINITE 2 MOD500TDMFA(6), MOD527TDMAF(6) (SPLTI)
P2-47863 BRKT THERMO MOD 1 MOD500TDMFA(6), MOD527TDMAF(6) (SPLTI)
P2-37809 BRKT CONT MTG MOD 1 M500 INFINITE
22 2E-306865 CONTROL LIQ LEVEL 208/240 1 AUTOFILL UNITS
23 2I-40034 GROMMET SCREW T4 4 AUTOFILL UNITS
24 2K-33996X FTG FLEX CONDUIT 90X3/8 2
25 2I-Z12311 GASKET-FIBER WASHER 2
26
P2-35004 COVER BOTTOM 200 SERIES
1
M500
P2-307110
COVER BOTTOM MOD300
SERIES
P2-300712 COVER BOT MOD227/427TDM/A
M527
P2-300704 COVER BOT MOD327/527TDM/A
27 P2-303359 SHROUD SIDE MODS ROHS 2 M500
28
P2-Z14627 SHROUD, FRONT M4
1
M500, 427, DIGITAL
P2-48191 SHROUD REAR MOD 500 527 M500
P2-303376 SHROUD FRONT MOD 500 527T M500 INFINITE & T-STAT
29 2H-36050 INSUL FG .6 MICRO 1/36
SOLD BY FOOT
30 2H-36196 INSUL FG .6 MICRO 1X45 SOLD BY FOOT
31
P2-WL0082 PAN ELEM ASSY
5
M500 DIGITAL
P2-WL0096 PAN ELEM ASSY MOD 227-527 M527 DIGITAL
WS-503843
KIT PAN ELEM W/ELEMENT
208/240
M500 T-STAT & INFINITE
WS-503840 KIT ELEM PAN W/ELEMENT M527 T-STAT
32
WS-50398 ELEM 240V 1200W M P
5
M500 INFINITE, 240V
2N-303375UL ELEM HEATING 240V 1650W M500 T-STAT, 240V
2N-300706UL ELEM 240V 1650W 12 X 27 M527
33
WS-55707 COVER ELEM MOD WARMER
5
M500, INFINITE UNITS
WS-503842 KIT ELEM PAN W/O ELEMENT M500, T-STAT & DIGITAL
WS-503841 KIT ELEM PAN W/O ELEMENT M527
34 D8-303352 BRKT THERMO BULB 4 THERMOSTAT UNITS
35 P2-WL0081 PAN ELEM ASSY MOD200-500 4 INFINITE 240V
36 WS-50374 THERMO, HI-LIMIT, SFTY, 550F 4 INFINITE UNITS
NI 2C-30397 CLIP ELEM WRMRS SML 36 VARIOUS OLDER UNITS
