EXPLODED VIEW and PARTS LIST (continued)
31
ITEM DESCRIPTION SVC P/N QTY
1 ASSY, CAVITY 1
2 TERMINAL BLOCK, 3 POLE 50131 1
3 SPACER, BLOWER MOTOR 4
4 LUG, SOLDERLESS 1
5 FAN, COOLING 64687 1
6 PANEL, CONTROL 1
7 MOTOR, 1/4 HP 63932 1
7.1 START CAPACITOR 69823 1
7.2 BRACKET, START CAPACITOR 500933 1
8 SPACER, MOTOR MOUNT 4
9 BLOWER WHEEL 63797 1
10 BRACKET, MOTOR MOUNT 1
11 SSR MODULE 504615 2
12 RELAY, E-SAFE 504892 1
14 GROMMET, 7/8" O.D. 51040 2
18 TRANSFORMER 505804 1
23 READER, MAGNETIC CARD 504626 1
24 BRACKET, HI-LIMIT THERMO 1
25 THERMOSTAT, HI-LIMIT 65180 1
26 THERMOCOUPLE 504850 1
28 LABEL, GROUND SYMBOL 64584 1
31 ASSY, PROXIMITY SWITCH 65239 1
34 FUSEHOLDER, 10A 240V 54769 2
40 INSULATION, MOTOR MOUNTING 1
42 ASSY, FRAME 504609 1
43 FUSE, 10A 240V 54871 2
59 BRACKET, PROX SWITCH 63787 1
62.1 INNER ELEMENT, 208V (4" GAP) 63872 1
62.2 INNER ELEMENT, 240V (4" GAP) 63783 1
63.1 MIDDLE ELEMENT, 208V (2.5" GAP) 63866 1
63.2 MIDDLE ELEMENT, 240V (2.5" GAP) 63800 1
64.1 OUTER ELEMENT, 208V (1" GAP) 63873 1
64.2 OUTER ELEMENT, 240V (1" GAP) 63949 1
66 ASSY, POWER CORD 1
67 STRAIN RELIEF 68754 1
67.1 NUT (ONLY), STRAIN RELIEF 65504
70 GASKET, ELEMENT 63834 1
71 COVER, ELEMENT GASKET INNER 63836 1
72 COVER, ELEMENT GASKET OUTER 63837 1
81 TIME & TEMPERATURE CONTROLER 504616 1
89 SWITCH, ON/OFF 505295 1
90 WIRE SET (not shown) 1
91 SLEEVING, FIBREGLASS (not shown) 1
92 TIE, WIRE, STANDOFF (not shown) 2
93 OP. MANUAL M4200 (not shown) Lit 304618 1
