Wen 3401

EXPLODED VIEW AND PARTS LIST
No. Part No. Description Qty.
1 3401-001 Roller Base & Handle 1
2 3401-002 End Cap 1
3 3401-003 Caster With Braking 2
6 3401-006 Washer 16
7 3401-007 Cap Nut 4
8 3401-008 Handle Cover 1
10 3401-010 Hex Nut 8
11 3401-011 Mounting Bracket 1
13 3401-013 Hex Head Bolt 4
14 3401-014 Washer 6
15 3401-015 Hex Head Bolt 9
16 3401-016 Collector Body 1
17 3401-017 Safety Screen 1
18 3401-018 Inlet Cover 1
19 3401-019 Clamp 1
20 3401-020 Collection/Filtration Bag 1
21 3401-021 Hex Nut 1
22 3401-022 Washer 1
23 3401-023 Impeller 1
24 3401-024 Inner Gasket 1
25 3401-025 Collector Cover 1
26 3401-026 Outer Gasket 1
27 3401-027 Washer 5
28 3401-028 Hex Head Bolt 4
30 3401-030 Motor Key 1
31 3401-031 Motor Mounting Bracket 1
32 3401-032 Switch Cover Plate 1
34 3401-034 Phillips Head Screw 2
35 3401-035 Switch 1
36 3401-036 Phillips Head Screw 1
37 3401-037 Lock/Spring Washer 1
38 3401-038 Motor Brush 2
39 3401-039 Brush Cover 2
40 3401-040 Cord Clamp 1
41 3401-041 Power Cord 1
42 3401-042 Inlet Seal 1
43 3401-043 Caster Without Braking 2
44 3401-044 Screw 4x16 2
45 3401-045 Switch Box 1
46 3401-046 Motor 1
47 3401-047 Toothed Washer 1
48 3401-048 Big Flat Washer 3
