TABLE OF CONTENTS
Specifications .................................................................................. 2
Introduction .................................................................................... 3
General Safety Rules ....................................................................... 4
Specific Safety Rules for the Wood Lathe ........................................ 6
Electrical Information ...................................................................... 8
Know Your Wood Lathe ................................................................... 9
Assembly & Adjustments .............................................................. 10
Operation ...................................................................................... 15
Maintenance .................................................................................. 21
Troubleshooting Guide .................................................................. 22
Exploded View & Parts List ........................................................... 23
Warranty Statement ....................................................................... 26
SPECIFICATIONS
Model Number 34027
Motor 120 V, 60 Hz, 4.5A, S6 40%
Swing Over Bed 12 in.
Distance Between Centers 16 in.
Spindle Thread 1"-8
Speeds 500 to 2500 RPM
Spindle Taper MT2
Tailstock Taper MT2
Tool Rest Length 7-7/8 in.
Dimensions 32 x 9 x 17 in.
Weight 72.1 lbs.
