EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty
46 34034-046 Handwheel Handle 1
47 34034-047 Set Screw 1
48 34034-048 Tailstock Lock Lever 1
50 34034-050 Tailstock Clamp Bolt 1
51 34034-051 Tailstock Clamp 2
52 34034-052 Lock Nut, M12 2
53 34034-053 C-Ring 1
57 34034-057 C-Ring 2
59 34034-059 Lock Lever 1
60 34034-060 Tool Rest Clamp Bolt 1
71 34034-071
Phillip Head Screw,
M4X8
2
75 34034-075 RPM Digital Readout 1
77 34034-077 Wrench 1
78 34034-078 Hex Wrench 3mm 1
79 34034-079 Hex Wrench 4mm 1
80 34034-080 Hex Wrench 5mm 1
81 34034-081 Hex Wrench 12mm 1
82 34034-082 Handle Sleeve 1
85 34034-085 Power Plug 1
98 34034-098 Headstock Cover 1
99 34034-099 Washer 3
100 34034-100 Washer 1
200 34034-200 Electrical Box Assembly 1
201 34034-201 Motor 1
202 34034-202 Motor Plate 1
203 34034-203 Motor Pulley 1
204 34034-204 Spindle Pulley 1
205 34034-205 Belt 1
206 34034-206 Spindle 1
207 34034-207
Tool Rest Base Lock
Lever
1
208 34034-208 Tool Rest Base 1
209 34034-209 Tool Rest 1
210 34034-210 Electrical Box Bracket 2 1
211 34034-211 Electrical Box Bracket 1 1
212 34034-212 Washer 6
213 34034-213 Screw, M5X10 6
214 34034-214 Screw, M8X10 4
215 34034-215 Carbon Brush 2
216 34034-216 Carbon Brush Cap 2
No. Part No. Description Qty
1 34034-001 Foot 4
3 34034-003
Belt Tension Lock Lever,
M8X20
1
4 34034-004 Washer 2
6 34034-006 Head Cap Screw, M6X16 4
9 34034-009 Cap Screw, M8X16 1
10 34034-010 Bed 1
11 34034-011 Lower Belt Door 1
12 34034-012
Phillip Head Screw,
M5X10
7
13 34034-013 Screw, M5X14 1
14 34034-014 Head Screw, M8X12 4
15 34034-015 Washer 8
16 34034-016 Handle With Tool Rack 2
17 34034-017 Cap Screw 4
18 34034-018 Spring Washer 4
19 34034-019 Headstock Body 1
20 34034-020
Spindle Speed Sensor,
M8X20
1
21 34034-021 Spindle Lock Assembly 1
24 34034-024 Headstock Handwheel 1
25 34034-025 Locking Nut, M20*1.5X12 1
26 34034-026 Knockout Rod Assembly 1
27 34034-027 Upper Belt Door 1
28 34034-028 Cap Screw, M5X10 2
29 34034-029 Set Screw, M5X6 2
30 34034-030 Bearing, 6204 1
31 34034-031 Ring 2
32 34034-032 Bearing, 6005 1
34 34034-034 Cap Screw, M6X8 2
35 34034-035 Face Plate 1
36 34034-036 Spur Center 1
37 34034-037 Live Center 1
38 34034-038 Quill 1
39 34034-039 Tailstock 1
40 34034-040 Quill Lock Lever 1
41 34034-041 Pin 1
42 34034-042 Leadscrew 1
43 34034-043 Tailstock Wheel 1
44 34034-044 Handwheel Axle 1
45 34034-045 Washer 1
