12
EXPLODED VIEW AND PARTS LIST
Item Stock # Description Qty Item Stock # Description Qty
1 3602-001 Screw 13 28 3602-028 Bearing bracket 1
2 3602-002 Dust tube 1 29 3602-029 Cutter lifting connector 1
3 3602-003 O-ring 1 30 3602-030 Balance pin 4
4 3602-004 Right housing 1 31 3602-031 Balancing weight 1
5 3602-005 Brush holder 2 32 3602-032 Bearing 1
6 3602-006 Brush carrier 2 33 3602-033 Gear 1
7 3602-007 Brush 2 34 3602-034 Washer 1
8 3602-008 Bearing 1 35 3602-035 Clamp spring 1
9 3602-009 Label clip 1 36 3602-036 Bearing sleeve 1
10 3602-010 Switch 1 37 3602-037 Ball sliding block 1
11 3602-011 Cable 1 38 3602-038 Reciprocating lever 1
12 3602-012 Cable guard 1 39 3602-039 Locating board 1
13 3602-013 Left housing 1 40 3602-040 Cutter spring pocket 1
14 3602-014 Left housing coat 1 41 3602-041 Cutter lifting pocket 1
15 3602-015 Speed dial 1 43 3602-043 Wire foam 1
16 3602-016 Screw 1 44 3602-044 Blade 1
18 3602-018 Insert plate 2 45 3602-045 Base plate set 1
19 3602-019 Screw 5 46 3602-046 Base press plate 1
20 3602-020 Cutter lifting knob 1 47 3602-047 Hexagonal screw 2
21 3602-021 Pressure spring 1 48 3602-048 Guide wheel 1
22 3602-022 Steel ball 1 49 3602-049 Guide wheel pin 1
23 3602-023 Clamp spring 1 50 3602-050 Cutter lifting reset spring 1
24 3602-024 Stator 1 51 3602-051 Locating pin 1
25 3602-025 Armature 1 52 3602-052 Right housing coat 1
26 3602-026 Bearing 1 54 3602-054 Hex wrench 1
27 3602-027 Screw 2 55 3602-055 Screw 6
