MITER CUTS
The base plate can be tilted to cut any angle between
0º and 45º right and left.
Loosen the two base plate adjustment screws. Then
slide the base plate toward the back of the saw. Rotate
the base left or right to the desired angle, slide the base
plate forward until the blade guide is in the correct
position, then tighten base plate screws. Note: the base
plate has a scale for setting 45º and 90º angles. Use a
protractor to set other angels.
10
