EXPLODED VIEW AND PARTS LIST
No. Part Number Description Qty.
1 Blade Tension Cap Assembly 1
1-1 Tension Lock Knob 1
1-2 Spindle Cover 1
1-3 Bar Cover 1
1-4 Cover Seal 1
2 40417-002 Chain 1
3 40417-003 Guide Bar 1
4 40417-004 Sheath 1
5 40417-005 Oil Feed Seal 1
6 40417-006 Screw 22
7 40417-007 Screw 2
8 40417-008 Insulating Washer 1
9 40417-009 Tension Adjusting Knob 1
10 40417-010 Tension Ajustment Rod 1
11 40417-011 Screw 3
12 40417-012 Bucking Teeth 1
13 40417-013 Right Housing 1
14 40417-014 Screw 4
15 40417-015 Upper cover 1
16 Brake Handle Assembly 1
16-1 Brake Handle 1
16-2 Guard Plate 1
16-3 Screw 2
17 40417-017 Oil Outlet Nozzle 1
18 40417-018 Housing Vent 1
19 40417-019 Battery Pack Release Spring 1
20 40417-020 Battery Pack Release Lever 1
21 40417-021 Lock 1
40417-001
40417-016
No. Part Number Description Qty.
22 40417-022 Bake Spring 1
23 40417-023 Clamp 1
24 40417-024 Motor 1
25 40417-025 Shaft 1
26 40417-026 Spring 1
27 40417-027 Screw 1
28 40417-028 Torsion Spring 1
29 40417-029 Trigger 1
30 40417-030 Safety Button 1
31 40417-031 Safety Spring 1
32 40417-032 PCB 1
33 Oil Tank Assembly 1
33-1 Oil Tank 1
33-2 Filter 1
33-3 Seal 1
33-4 Oil Tube (90) 1
33-5 Spring (60) 1
34 40417-034 Left Housing 1
35 40417-035 Handle 1
36 40417-036 Rubber Washer 1
37 Oil Cap Assembly 1
37-1 Hanger 1
37-2 Seal Ring 1
37-3 Oil Cap 1
38 40417-038 Oil Tube (120) 1
39 40400 Charger 1
40 40404 4.0Ah Battery 1
40417-033
40417-037
