Wen 4208 User Manual

KNOW YOUR DRILL PRESS
TOOL PURPOSE
Drill clean, precise cylindrical holes into workpieces or enlarge existing holes with your Drill Press. Refer to the fol-
lowing diagrams to become familiarized with all the parts and controls of your Drill Press. The components will be
referred to later in the manual for assembly and operation instructions.
10
Speed Chart
Spindle Pulley
Housing Cover
Chuck Key
Chuck
Motor
Feed Handle
Belt Tension
Base
Table
Table Lock
HOUSING
Belt
Motor Pulley
ON/OFF Switch
Spindle Return
Column
DRILL PRESS
Depth Stop
