Wen 4210

2
Table of Contents
Technical data………………………………………………………………….. 2
General safety rules…………………………………………………………….. 3
Specific safety rules for drill presses…………………………………………… 5
Electrical information…………………………………………………………... 6
Know your drill press…………………………………………………………… 8
Assembly and adjustments……………………………………………………… 9
Operation………………………………………………………………………... 21
Maintenance…………………………………………………………………….. 25
Exploded view…………………………………………………………………... 26
Parts list………………………………………………………………………….. 27
Warranty………………………………………………………………………… 28
Technical data
10" Drill Press with Laser Crosshair
Item: 4210
Motor: 120 V, 60 Hz, 3.2 A
Horsepower: 1/3 HP (single phase)
Motor speed: 1700 RPM (no load)
Drilling capacity: 2-1/4"
Chuck capacity: 0–1/2"
Pulley speeds: 5 (570, 900, 1390, 2050, 3050 RPM)
Table size: 7-5/8" x 7-5/8"
Chuck to table: 9-3/8” – maximum capacity
Laser module: Class II
Laser wavelength: 660 nm
Laser output: 1 mW
Overall height: 28-1/4"
Weight: 55 lb
