Wen 4214

TABLE OF CONTENTS
Technical Data
2
3
4
5
7
8
16
19
20
21
24
General Safety Rules
Specific Safety Rules For Drill Press
Electrical Information
Know Your Drill Press
Assembly and Adjustments
Operation
Maintenance
Exploded View and Parts List
Warranty
TECHNICAL DATA
Model Number:
Motor:
Speed:
Chuck Capacity:
Stroke:
Capacity:
Table tilt:
Laser:
Weight:
4214
120 V, 60 Hz, 5 A
580-3200 RPM (no load)
1/8--5/8˝
3-1/8˝
6˝ (chuck to column)
20˝ (chuck to base)
0 to 45° left and right
Class III, transformer powered
85 lb
2
Troubleshooting
