EXPLODED VIEW AND PARTS LIST

Item Stock # Description Item Stock # Description

61 56206-061 Washer 6 79 56206-079 Bolt M8×50

62 56206-062 Washer 80 56206-080 Cylinder

63 56206-063 Oil seal 48.7×3.55G 81 56206-081 Ring58×52.5×4

64 56206-064 Nut M6 82 56206-082 Oil seal43.7×3.55G

65 56206-065 Front bracket 83 56206-083 Piston

66 56206-066 Upper pad 84 56206-084 stud

67 56206-067 Push rod 85 56206-085 stud

68 56206-068 Tine plate 86 56206-086 Spring

69 56206-069 Bolt M4×6 87 56206-087 Rear cover

70 56206-070 Down pad 88 56206-088 Oil seal 3.6×1.8G

71 56206-071 Nut M14 89 56206-089 Bleed screw

72 56206-072 Rubber plug 90 56206-090 Oil seal30×2.65G

73 56206-073 Work table guard 91 56206-091 Washer FC30×38×5

74 56206-074 Back bracket 92 56206-092 Dipstick

75 56206-075 Beam 93 56206-093 Oil seal 11.8×2.65G

76 56206-076 Step bolt M6×50 94 56206-094 Knob

77 56206-077 Work table guard 95 56206-095 Piston rod

78 56206-078 Rubber handle 96 56206-096 lock nut M14
