18
EXPLODED VIEW AND PARTS LIST
Item Stock # Description Item Stock # Description
1 56206-001 Motor 31 56206-031 Bracket
2 56206-002 Nut M6 32 56206-032 Bolt
3 56206-003 Rubber foot 33 56206-033 Rubber sleeve
4 56206-004 Right rubber foot 34 56206-034 Hydraulic control lever
5 56206-005 bolt M6×12 35 56206-035 Nut M10
6 56206-006 Left rubber foot 36 56206-036 Nut M10
7 56206-007 Nut M8 37 56206-037 Spring washer 10
8 56206-008 Washer 38 56206-038 Oil seal 9.5×2.65G
9 56206-009 Bearing bush 39 56206-039 Plastic cover
10 56206-010 Claboard 40 56206-040 BoltM6×20
11 56206-011 Steel ring10 41 56206-041 Hexagon nut
12 56206-012 Gear 42 56206-042 Bush for shaft
13 56206-013 Gear shaft 43 56206-043 Oil seal 4.87×1.8G
14 56206-014 Steel ball 2.5 44 56206-044 Shaft
15 56206-015 Round pin 2.5×4 45 56206-045 Adjustment spring
16 56206-016 Bolt M8×30 46 56206-046 Cone valve
17 56206-017 Spring washer 8 47 56206-047 Oil valve
18 56206-018 Flat washer 8 48 56206-048 Screw
19 56206-019 Bolt M8×55 49 56206-049 Oil seal 11.8×2.2G
20 56206-020 Shaft 50 56206-050 Hexagon bolt
21 56206-021 Cover 51 56206-051 Bolt
22 56206-022 Oil seal 10×2.65G 52 56206-052 Washer16×t1
23 56206-023 Bolt M6×12 53 56206-053 Oil seal 14×1.8G
24 56206-024 Spring washer 6 54 56206-054 spring
25 56206-025 Flat washer 6 55 56206-055 Front cover
26 56206-026 Locking nut M10 56 56206-056 Control valve
27 56206-027 Flat washer 10 57 56206-057 Oil seal 11.2×1.8G
28 56206-028 Wheel 58 56206-058 Journey valve
29 56206-029 Wheel shaft 59 56206-059 Oil seal 5.6×1.8G
30 56206-030 Pin3.2×20 60 56206-060 Spring
To Next Page
