KNOW YOUR BENCH GRINDER
9
5
6
7
1
2
3
9
10
8
4
1 INNER WHEEL GUARD - Covers the
grinding wheels and protects against
accidental contact.
7 WHEEL COVER - Covers the grinding
wheels and provides quick access for
routine maintenance.
2 TOOL RESTS - Used to support the
workpiece that is being ground.
Adjustable to provide angled surfaces.
8 GRINDING WHEEL 60 GRIT - Used to
remove light material from workpiece.
3 GRINDING WHEEL 120 GRIT - Used
to remove light material from workpiece.
9 ON/OFF SWITCH - Used to turn the
grinder ON and OFF.
4 EYESHIELD - Protective Lexan
see-thru shields to prevent any loose
debris from contacting the operator.
10MOTOR HOUSING - Contains the
electrical motor.
5 LOCKING KNOB-Lock the eyeshield
in position.
6 SPARK ARRESTOR - Prevents hot
sparks and debris from contacting the
operator.
