Wen 4286 Operator's Manual

15
PARTS LIST
Item Stock # Description Item Stock # Description
1 4286-001 Screw 30 4286-030 Lock washer
2 4286-002 Bolt 31 4286-031 Screw
3 4286-003 Left guard cover 32 4286-032 Switch
4 4286-004 Nut 33 4286-033 Screw
5 4286-005 Flange 34 4286-034 Switch plate
6 4286-006 Grinding wheel 120# 35 4286-035 Lock washer
7 4286-007 Screw 36 4286-036 Bolt
8 4286-008 Lock washer 37 4286-037 Cover
9 4286-009 Spark deflector 38 4286-038 Foot
10 4286-010 Flat washer 39 4286-039 Screw
11 4286-011 Left eyeshield (magnifier) 40 4286-040 Capacitor
12 4286-012 Left eyeshield support 41 4286-041 Capacitor support
13 4286-013 Knob 42 4286-042 Nut
14 4286-014 Flat washer 43 4286-043 Ball bearing
15 4286-015 Lock washer 44 4286-044 Armature
16 4286-016 Bolt 45 4286-045 Base
17 4286-017 Left guard 46 4286-046 Strain relief plate
18 4286-018 Hex flange nut 47 4286-047 Strain relief
19 4286-019 Left toolrest support 48 4286-048 Power cord
20 4286-020 Flat washer 49 4286-049 Right eyeshield support
21 4286-021 Knob 50 4286-050 Right eyeshield
22 4286-022 Left tool rest 51 4286-051 Screw
23 4286-023 Knob 52 4286-052 Right tool rest
24 4286-024 End shield 53 4286-053 Right toolrest support
25 4286-025 Washer 54 4286-054 Right guard
26 4286-026 Stator 55 4286-055 Grinding wheel 60#
27 4286-027 Grommet 56 4286-056 Nut
28 4286-028 Washer 57 4286-057 Right guard cover
29 4286-029 Flat washer

