No. Part No. Description Spec Qty.
1 56035-E-000 Engine 1
2 56035-147 Key 5*40 1
3 56035-020 Pulley 1
4 56035-019 Washer M8×30×6 1
5 56035-018 Spring Washer Ø 8 5
6 56035-017 Hex Bolt M8*30 1
7 56035-005-3 Washer Ø 10 6
8 56035-048 Handle Fixed Plate 2
9 56035-049 Handle Rubber Damper 4
10 56035-050 Lock Nut M12 2
11 56035-005L Lower Handle 2
12 56035-051 Locked Pin Assembly M10*35 2
13 56035-005H Upper Handle 1
14 56035-046 Throttle Line Assembly 1
15 56035-005-2 Lock Nut M10 2
16 56035-005-6 Flange Bolt M10*35 2
17 56035-005-7 Handle Damper 2
18 56035-005-4 Washer Ø 10 14
20 56035-015 Belt Cover 1
21 56035-014 Washer Ø8*24 2
22 56035-012 Bolt M8*20 2
23 56035-030 Bottom Plate 1
24 56035-031-1 Engine Support Plate 1
25 56035-035 Lock Nut M12 4
PLATE COMPACTOR
EXPLODED VIEW & PARTS LIST
No. Part No. Description Spec Qty.
26 56035-003 Washer 12*35 4
27 56035-032 Shock Absorber 4
28 56035-028 Washer Ø12 4
29 56035-027 Spring Washer Ø12 4
30 56035-026 Nut M12 4
31 56035-052 Lock Nut M8 4
32 56035-005-8 Hex Bolt M10*65 2
33 56035-009 Washer Ø8 4
34 56035-053 Hex Bolt M8*45 2
35 56035-024 Hex Bolt M18*140 2
36 56035-025 Press Plate 1
37 56035-031-2 Exciter Seat 1
38 56035-023 Vibrator Assembly 1
39 56035-022 Spring & Flat Washer Ø18 2
40 56035-021 Nut M18 2
41 56035-016-2 Belt, 17 x 787 B-787 1
42 56035-038 Hex Bolt M12*35 8
43 56035-037 Spring Washer Ø12 8
44 56035-036 Flat Washer Ø12 8
45 56035-043 Nut M8 2
46 56035-042 Hex Bolt M8*50 2
47 56035-002 Hex Bolt M10*30 1
49 56035-001 Frame 1
50 56035-054 Washer Ø18 2
NOTE: Not all parts may be available for purchase. Parts and accessories that wear
down over the course of normal use are not covered under the warranty.
22
