EXPLODED VIEW & PARTS LIST
No. Part No. Description No. Part No. Description No. Part No. Description
1 61782B-001 Screw M5x20 36 61782B-036 Adjuster 71 61782B-071 Pin
2 61782B-002 Bushing 37 61782B-037 Bracket Assembly 72 61782B-072 O ring 24.3x2.8
3 61782B-003 Exhaust Cover 38 61782B-038 Nut M3 73 61782B-073 Feed Hook
4 61782B-004 Washer 39 61782B-039 Spring Pin 3x28 74 61782B-074 Washer
5 61782B-005 Screw M5x30 40 61782B-040 Safe Bracket Guide 75 61782B-075 Feed Hook Pin
6 61782B-006 Spring Washer 41 61782B-041 O ring 7.5x1.5 76 61782B-076 Torsion Spring
7 61782B-007 Cylinder Cap 42 61782B-042 Screw M6x35 77 61782B-077 Piston
8 61782B-008 Gasket 43 61782B-043 Washer 78 61782B-078 O ring 12.3x1.9
9 61782B-009 O ring 36.3x2.5 44 61782B-044 Latch 79 61782B-079 Piston Bumper
10 61782B-010 O ring 55.4x3 45 61782B-045 Pin 80 61782B-080 Spring
11 61782B-011 Spring 46 61782B-046 Washer 81 61782B-081 Cover
12 61782B-012 Valve 47 61782B-047 Pin 82 61782B-082 Locking Washer
13 61782B-013 O ring 40.2x2.3 48 61782B-048 Handle 83 61782B-083 Upper Nail Housing
14 61782B-014 Cylinder Seal 49 61782B-049 Stopped Hook 84 61782B-084 Adjuster Nut
15 61782B-015 Valve Seat 50 61782B-050 Spring 85 61782B-085 Pin 2.5x18
16 61782B-016 Stopped Washer 51 61782B-051 Block Plate 86 61782B-086 Adjuster Plate
17 61782B-017 Washer 52 61782B-052 Spring Washer 87 61782B-087 Washer
18 61782B-018 O ring 43.3x3.5 53 61782B-053 Screw M4x12 88 61782B-088 Adjuster Stem
19 61782B-019 Piston Assy 54 61782B-054 Pin 89 61782B-089 Ball
20 61782B-020 Cylinder 55 61782B-055 Shaft 90 61782B-090 Spring
21 61782B-021 O ring 50.5x2.5 56 61782B-056 Spring 91 61782B-091 Adjuster Bushing
22 61782B-022 Restrictive Plate 57 61782B-057 Protector 92 61782B-092 Backing Plate
23 61782B-023 O ring 76.36x2.62 58 61782B-058 O ring 10.3x1.9 93 61782B-093 Pin
24 61782B-024 Cylinder Sleeve 59 61782B-059 O ring 20.3x1.5 94 61782B-094 Lower Nail Housing
25 61782B-025 Bumper 60 61782B-060 Valve Set 95 61782B-095 Screw M4x10
26 61782B-026 Protective Piece 61 61782B-061 Trigger Valve Guide 96 61782B-096 Nut M6
27 61782B-027 Soft Spacer 62 61782B-062 Spring 97 61782B-097 Connected Plate
28 61782B-028 Body 63 61782B-063 O ring 9.5x1.9 98 61782B-098 Support
29 61782B-029 O ring 46x1.3 64 61782B-064 O ring 20.3x2.5 99 61782B-099 Bracket
30 61782B-030 Restrictive Washer 65 61782B-065 O ring 12.8x1.9 100 61782B-100 Screw M6x10
31 61782B-031 Nose 66 61782B-066 Trigger Valve Head 101 61782B-101 Soft Grip Sleeve
32 61782B-032 Spring Washer 67 61782B-067 O ring 5.5x1.5 102 61782B-102 O ring 65.4x2.5
33 61782B-033 Screw M6x25 68 61782B-068 Spring 103 61782B-103 End Cap
34 61782B-034 Bracket 69 61782B-069 Trigger Valve Stem 104 61782B-104 Air Plug
35 61782B-035 Spring 70 61782B-070 Trigger Assembly
