Wen 6307 Manual

EXPLODED VIEW AND PARTS LIST
11
No Part Number Description Qty.
31 6307-031 Screw 1
32 6307-032 Belt Plate 1
33 6307-033 Screw 2
34 6307-034 Belt Housing 1
35 6307-035 Nut 1
36 6307-036 Arm Support 1
37 6307-037 Screw 8
38 6307-038 Label 1
39 6307-039 Adjustment Knob 1
40
6307-103
Button 1
41 Spring 1
42 Lock 1
43 6307-043 Spring 1
44
6307-104
Arm 1
45 Support Plate 2
46 Rivet 2
47 Bearing 608-2RS 1
48 Pin 1
49 Base Plate 1
50 Rivet 1
51 6307SP Sanding Belt 1
52
6307-105
Screw 3
53 Dust Port Clip 1
54 Dust Port Sleeve 1
55 6307-055 Rubber Insert 1
101 6307-101 Rotor Assembly 1
102 6307-102 Gear Assembly 1
103 6307-103 Button Assembly 1
104 6307-104 Belt Support Assembly 1
105 6307-105 Dust Port Assembly 1
No Part Number Description Qty.
1 6307-001 Power Cord 1
2 6307-002 Power Cord Sleeve 1
3 6307-003 Switch 1
4 6307-004 Screw 1
5 6307-005 PCB Board 1
6 6307-006 Screw 2
7 6307-007 Cord Clamp 1
8 6307-008 Left Housing 1
9 6307-009 Label 1
10 6307-010 Drum 1
11 6307-011 Nut 1
12 6307-008 Right Housing 1
13 6307-013 Stator 1
14 6307-014 Bearing Washer 626-2RS 1
15
6307-101
Bearing 626-2RS 1
16 Rotor 1
17 6307-017 Bearing 626-2RS 1
18 6307-018 Pin 1
19 6307-019 Sleeve 1
20 6307-020 Gear 1
21 6307-021 Retaining Ring 1
22 6307-022 Carbon Brush 2
23 6307-023 Brush Holder 2
24
6307-102
Bearing 608-2RS 1
25 Gear 1
26 Shaft 1
27 Pin 1
28 Bearing 608-2RS 1
29 6307-029 Screw 1
30 6307-030 Belt Cover 1
31 6307-031 Screw 1
