EXPLODED VIEW AND PARTS LIST
No. Part Number Description Qty.
1 6369-001 M6X15 Screw 1
2 6369-002
Ø
6 Washer 1
3 6369-003 Sanding Pad 1
4 6369-004 Output Shaft 1
5 6369-005 Flat Key 3X3X10 1
6 6369-006 Oil Seal 1
7 6369-007 Collar
Ø
22 1
8 6369-008 Ball Earing 6900 Rs 1
9 6369-009 Screw M4*12 6
10 6369-010 Big Bearing Cover 1
10A 6369-011 Paper Washer 1
11 6369-012 End Gear 1
12 6369-013 Collar
Ø
10 1
13 6369-014 Ball Bearing 606 Z 2
15 6369-015 Small Bearing Cover 1
16 6369-016 Ball Bearing 699 Z 1
16A 6369-017 Collar Ø22 1
17 6369-018 Main Driving Shaft 1
17A 6369-019 Washer 1
18 6369-020 Semi-Circular Key 3X3X10 1
19 6369-021 Tapered Gear 1
19A 6369-022 Washer 1
20 6369-023 Collar
Ø
9 1
21 6369-024 Gear Box 1
22 6369-025 Middle Cover 1
22A 6369-026 Spring Of Rotor 1
22B 6369-027 Wool Cap 1
23 6369-028 Rotor 1
23A 6369-029 Anti-Dust Ring 1
24 6369-030 Ball Bearing 607 Rs 1
25 6369-031 Anti-Wind Ring 1
26 6369-032 Screw St4*55 2
26A 6369-033 4.2 Circular Button 1
27 6369-034 Stator 1
27A 6369-035 Sleeve 1
28 6369-036 Motor Housing 1
28A 6369-037
Ø
4 Flat Washer 4
28B 6369-038
Ø
4 Flexible Washer 4
29 6369-039 Screw M4*20 4
30 6369-040 Brush Holder 2
31 6369-041 Carbon Brush 2
32 6369-042 Screw St3*10 4
33 6369-043 Coil Spring 2
34 6369-044 Back Cover 1
34A 6369-045 Screw St4*12 2
35 6369-046 Screw St4*14 42
36 6369-047 Pressing Block On Motor Housing 1
37 6369-048 Vibration Damping 2
38 6369-049 Big Rubber Sleeve 2
39 6369-050
Screw Pin
2
40 6369-051 Flexible Sleeve 1
41 6369-052 Brush Segment 1
No. Part Number Description Qty.
42 6369-053 Sanding Pad Cover 1
48 6369-054 Tightening Ring 25-38
1
49
6369-055 350 Hose
1
50
6369-056 Small Cable Sleeve
1
51 6369-057 Small Rubber Cover
2
52 6369-058 Right Handle Stand
1
53 6369-059 Ø28 Connector
2
54 6369-060 Plastic Soft PipeØ28
1
55 6369-061 Ellipticle Connector
1
57 6369-062 Left Handle Stand
1
58 6369-063 Washer Ø4
4
59 6369-064 Compressed Spring
4
60 6369-065 Electric Sensor
2
61 6369-066 Cable Plate
2
62 6369-067 Electric Capacity
1
63 6369-068 Electronic Speed Control Plate
1
64 6369-069 Potentiometer
1
65 6369-070 Speed Button
1
67 6369-071 Cable
1
68 6369-072 Cable Sleeve
1
69 6369-073 Left Main Handle
1
70 6369-074 Aluminium Pipe Insert
1
71 6369-075 Cable Pressing Plate
1
72 6369-076 Left Sub-Handle
1
73 6369-077 Aluminium Pipe
1
73A 6369-078 Back Hinge Sleeve
1
73B 6369-079
Ø
5X45Pin
1
73C 6369-080
Ø
5 Clinch Bolt
2
73D 6369-081
Ø
1.2 Sealed Ring
1
73E 6369-082 Front Hinge Sleeve
1
73F 6369-083 Aluminium Pipe
1
73M 6369-084 Supporting Arm
2
73P 6369-085
Pin
Ø
5X30 1
73Q 6369-086
Pin
Ø
5X16.8 1
73H 6369-087 Sleeve 2#
1
73I 6369-088 Front Latch
1
73J 6369-089 Spring
1
73K 6369-090 Latch Pivot
1
73L 6369-091 Fixed Plate
1
74 6369-092 Aluminium Pipe With Single Access
1
75 6369-093 Switch
1
76 6369-094 Switch Pushing Lever
1
77 6369-095 Switch Button
1
78 6369-096 Right Sub-Handle
1
79 6369-097 Circular Pin
Φ
1.5X11.8
1
80 6369-098 Back Screw Nut
2
81 6369-099 Right Main Handle
1
82 6369-100 Hose Connection Adapter
1
83 6369-101 Adjustable Ring
1
84
6369-102
Connection Adapter 1
/ 6369-103 Flexible Hose
1
/ 6369-104 Dust Port Connection Adapter
1
